SKY RADIO?
? un dispositivo di aiuto alla manovra che permette di rilevare la vicinanza a
linee elettriche ad alta tensione in campo libero da parte di operatori di
pompe per calcestruzzo beton pompe
a nastri per autobetoniere.
Malgrado tutta la vigilanza, la professionalit? e l?esperienza sul terreno degli operatori, alcuni incidenti continuano ad accadere.
Il sistema ? costituito da una serie di sensori radio
da applicare al braccio della pompa, che comunicano con una centralina che allerta
l?operatore quando l?attrezzatura si avvicina a una distanza di pericolo a una
linea ad alta e ad altissima tensione.
SKY
RADIO Viene montato sia su attrezzature nuove (dal costruttore) sia usate, presso
officine autorizzate.
Il Vostro Migliore investimento:
Un
investimento minimo comparato ai vostri vantaggi immediati: L?immagine di una
societ? cosciente dei rischi che corre il suo personale. Un impegno etico, di
fronte ai vostri operatori. Un aiuto supplementare ad evitare incidenti.
Tecnologia e fabbricazione 100% Made in Europe.
| SKY RADIO 2
Un valido sistema di AIUTO al rilevamento in remoto di medie alte ed altissime tensioni nei cavi aerei.
SkyRadio2 pu? essere equipaggiato da 1 sino a 9 sensori indipendenti per rilevare le linee aeree ad alta tensione. Ogni sensore ? montato su una parte di un organo mobile della macchina. Per comunicare con l'unit? centrale (CPU), ogni sensore ha il proprio segnale radio trasmettitore-ricevente permanentemente connesso. La comunicazione radio ? assicurata da un canale di scansione dei canali radio per rilevare ed evitare possibili interferenze.
APPLICAZIONI
SKY RADIO is an operational aid which enables detection of the proximity of a high-voltage electric
line in a FREE FIELD. SKY RADIO warns the user by an audible signal and a warning light when high lift equipment approaches a 15 kV medium-voltage line at a distance of less than three meters or a 50 kV (or higher) line at a distance of less than 5 meters. A remote module enables the user to receive a warning signal at a distance of up to 100 m.
PRESENTAZIONE
SKY RADIO comprises from 1 to 8 independent sensors for the detection of the electric field. Each sensor
includes a radio transmitter/receiver module, which communicates continuously with the central processor
unit (CP). The radio communication is held secure by scanning the radio channel to detect any interference.
The CP has an antenna mounted on the vehicle roof and an internal clock to enable time-stamping of all the
memorised information.
OPERATION
SKY RADIO measures the electric field around a medium or high-voltage line and then by the analysis of this
measurement indicates the no-go zone not to enter (risk zone : three meters around a medium-voltage line, five meters around a high-voltage line : articles 172 and 173 of the law of 8 January 1965 modified by that of 6 May 1995). SKY RADIO indicates which sensor has detected the required level by an audible and light signal, and if
desired by temporarily stopping the movement. The sensors are continuously interrogated by the processing module in order to verify their operational state, the battery charge level and the operation of the various radio channels, so avoiding any failure which could be dangerous for the operating personnel (audible and light signal of the faulty sensor). Easy to install, SKY RADIO requires no adjustments.
TECHNICAL CHARACTERISTICS
|
Central Processor Unit
CP
|
Independent moulded
Sensors
|
Supply
|
12V / 24V
(from the vehicle)
|
By a battery in a waterproof
compartment
|
Dimensions
|
80 x 120 x 200 mm
|
60 x 1000 x 80 mm
|
Operating Temperature
|
-20? C ? +60? C
|
Waterproofness
|
IP 67
|
Measurement Precision
|
? 15 cm from a 15kV line IN A FREE FIELD AND WITHOUT
MULTIPLE FIELDS, ? 50 cm from a 50 kV line
|
STANDARDS :
NF EN 50082-1 : EMC
NF EN 61010-1 : Safety requirements for electrical equipment
MADE declines any responsibility should this equipment be used without conforming to the manufacturers specifications.
MADE cannot be held responsible for an accident by contact with high-voltage lines,
given the large diversity of specific cases encountered in the field (The measurements are calibrated in a free field).
| SKY RADIO 2
An operational AID system for the remote detection of medium and high voltage overhead electric lines.
The SkyRadio equipment is equipped with 1 to 9 independent sensors to detect High-Voltage lines. Each sensor is mounted on a part of the mobile organ of the machine. To communicate with the calculating unit, each sensor has its own radio emitter/receptor, permanently connected. Radio communication is secured by scanning radio channels to detect and avoid possible disturbances.
APPLICATION
SKY RADIO is an operational aid which enables detection of the proximity of a high-voltage electric
line in a FREE FIELD. SKY RADIO warns the user by an audible signal and a warning light when high lift equipment approaches a 15 kV medium-voltage line at a distance of less than three meters or a 50 kV (or higher) line at a distance of less than 5 meters. A remote module enables the user to receive a warning signal at a distance of up to 100 m.
PRESENTATION
SKY RADIO comprises from 1 to 8 independent sensors for the detection of the electric field. Each sensor
includes a radio transmitter/receiver module, which communicates continuously with the central processor
unit (CP). The radio communication is held secure by scanning the radio channel to detect any interference.
The CP has an antenna mounted on the vehicle roof and an internal clock to enable time-stamping of all the
memorised information.
OPERATION
SKY RADIO measures the electric field around a medium or high-voltage line and then by the analysis of this
measurement indicates the no-go zone not to enter (risk zone : three meters around a medium-voltage line, five meters around a high-voltage line : articles 172 and 173 of the law of 8 January 1965 modified by that of 6 May 1995). SKY RADIO indicates which sensor has detected the required level by an audible and light signal, and if
desired by temporarily stopping the movement. The sensors are continuously interrogated by the processing module in order to verify their operational state, the battery charge level and the operation of the various radio channels, so avoiding any failure which could be dangerous for the operating personnel (audible and light signal of the faulty sensor). Easy to install, SKY RADIO requires no adjustments.
TECHNICAL CHARACTERISTICS
|
Central Processor Unit
CP
|
Independent moulded
Sensors
|
Supply
|
12V / 24V
(from the vehicle)
|
By a battery in a waterproof
compartment
|
Dimensions
|
80 x 120 x 200 mm
|
60 x 1000 x 80 mm
|
Operating Temperature
|
-20? C ? +60? C
|
Waterproofness
|
IP 67
|
Measurement Precision
|
? 15 cm from a 15kV line IN A FREE FIELD AND WITHOUT
MULTIPLE FIELDS, ? 50 cm from a 50 kV line
|
STANDARDS :
NF EN 50082-1 : EMC
NF EN 61010-1 : Safety requirements for electrical equipment
MADE declines any responsibility should this equipment be used without conforming to the manufacturers specifications.
MADE cannot be held responsible for an accident by contact with high-voltage lines,
given the large diversity of specific cases encountered in the field (The measurements are calibrated in a free field).
|
